Description

Eaton GFCI Receptacle, Self-Test, 125 V, 20 A, 2 Pole, 10 kA Short Circuit, Grounding Type: Automatic, 3 Wires, 14 to 10 AWG Wire, Back, Side Wiring, NEMA 5-20R NEMA Rating, -35 to 66 deg C Operating, Polycarbonate/Steel/Thermoplastic/PVC, Brown, Dimensions: 4.19 in H x 1.69 in W

Detailed Product Specifications

Manufacturer Part Number:GF20B

Unit of Measure:EA

Feature:Slimmer design for easy installation, leaving more room for wires in the box

Feature:Automatically self-tests periodically to ensure GFCI protection

Feature:GFCIs incorporate lock out functionality to protect against mis-wired line-load connections and GFCI circuitry damage

Feature:Wider button wells for easy test and reset

Feature:Intuitive LED status indicators for trip and end of life states

Feature:Clean, modern industrial design with reduced top housing markings and neutral text direction on buttons

Feature:Meets and exceeds 10 kA short circuit testing and underwriters laboratories

Feature:Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper is used

Feature:External backwire clamps provide visual confirmation of secure termination

Color:Brown

Current Rating:20 A

Dimensions:4.19 in H x 1.69 in W

Grounding Type:Automatic

Material:Polycarbonate/Steel/Thermoplastic/PVC

Nema Rating:NEMA 5-20R

Number of Poles:2

Number Of Wires:3

Operating Temperature:-35 to 66 deg C

Short Circuit Current Rating:10 kA

Type:Self-Test

Voltage Rating:125 V

Wire Size:14 to 10 AWG

Wiring Type:Back Side
