Description
Alemite offers a selection of pumps to meet your fluid handling and dispensing needs. Each pump is designed to deliver reliable, consistent performance to keep your operation running smoothly.
CHEMICAL AND MATERIAL HANDLING PUMPS
Alemite Chemical and Material Handling pumps provide the capabilities and versatility needed for various applications. They are designed to deliver materials from original or bulk storage containers to the point of application.
Alemite Class I and 2 Pumps are designed to handle light to medium fluids (5 to 4,000 cp) such as inks and oils. The double ball downtube ensures positive priming for reliable operation. Recommended for dispensing applications.
LIGHT – MEDIUM DUTY
FEATURES:
• Stainless steel and carbon steel models suitable for pumping corrosive liquids
• 1/4″ air inlet • Stub pumps require downtube (included with 7216-4)
RECOMMENDED ACCESSORIES:
• Single Post Hoist (2741-4 or 2742-4) for models 7216-S3, 7216-4, 7880-C1
– Requires Adapter Plate (322593)
|
Product # |
Wetted Materials |
Drum Size |
Material Inlet |
Material Outlet |
Seal Material |
Pump Ratio |
Free Flow (per minute) |
Cycles |
Weight |
|
7216-4 |
Carbon Steel |
55 gallon (208 liter |
– |
1″ NPTF(f) |
PTFE and Nylon II |
1:1 |
14 gallon (53 liter) |
25 per gallon (5.6 per liter) |
14 lb (6.3 kg) |
|
7216-A4 |
Carbon Steel |
55 gallon (208 liter) |
– |
1″ NPTF(f) |
PTFE and Nylon II |
1:1 |
14 gallon (53 liter) |
25 per gallon (5.6 per liter) |
18 lb (8.2 kg) |
|
7216-S3 |
Stainless Stee |
55 gallon (208 liter) |
1″ NPTF(f) |
1″ NPTF(f) |
PTFE |
1:1 |
14 gallon (53 liter) |
25 per gallon (5.6 per liter) |
22 lb (10 kg) |
|
7216-B |
Carbon Steel |
55 gallon (208 liter |
– |
3/8″ NPTF(f) |
Buna |
2:1 |
7 gallon (26 liter) |
32 per gallon (7.2 per liter) |
18 lb (8.2 kg) |
|
7222-B4 |
Carbon Steel |
Stub |
1-1/2″ NPTF(f) |
1″ NPTF(f) |
Flouroelastomer |
1:1 |
14 gallon (53 liter) |
25 per gallon (5.6 per liter) |
12 lb (5.4 kg) |
|
7880-C1 |
Stainless Steel |
Stub |
1″ NPTF(f) |
3/8″ NPTF(f) |
PTFE |
2.5:1 |
7 gallon (26 liter) |
32 per gallon (7.2 per liter) |
14 lb (6.3 kg) |
