Description

Abuse-resistant thermoplastic construction. External cable clamp provides firm strain relief. Back wire terminal clamps for easy secure wiring. Triple combination head screws standard – Slot/Phillips/Robertson for use in the US and Canada. 1/4 to 11/16 in cord Dia.

Detailed Product Specifications

Manufacturer Part Number:L620P

Unit of Measure:EA

Feature:Abuse resistant thermoplastic construction

Feature:Back wire dead-front design

Feature:External cable clamp provides firm strain relief

Feature:Back wire terminal clamps for easy secure wiring

Feature:Triple combination head screws standard – Slot/Phillips/Robertson for use in the USA and Canada

Feature:Clear cover over wiring compartments allow easy inspection of wiring terminations

Feature:Individual wiring compartments with tapered channel for easy insertion of wires

Cable/Wire Size:1/4 to 11/16 in

Color:Black/White

Current Rating:20 A

Dimensions:2.23 in L x 1.82 in W

Grounding Type:Grounded

Material:Thermoplastic

NEMA Configuration:NEMA L6-20

Number of Poles:2

Number Of Wires:3

Type:Locking

Voltage Rating:250 V
