Description

Tin-plated copper stab to create a reliable, permanent and corrosion-resistant connection. Ensures its ground circuitry is functioning properly by automatically running diagnostic testing on a periodic basis. Should a problem be detected, the circuit breaker will trip and will need to be replaced. Unit provides protection against overloads, short circuits and ground faults. Class A 5 mA ground fault circuit interrupter. Wire range is #14 – 8 AWG CU/#12 – 8 AWG AL. UL listed. 3 in H x 2-1/4 in W x 4-1/2 in D, 0.858 lb.

Detailed Product Specifications

Manufacturer Part Number:THQL2130GFTP

Unit of Measure:EA

Actuator Type:Quick-Make Quick-Break

Current Rating:30 A

Frame Type:Q-Line

Interrupt Rating:10 kA

Mounting Type:Plug

Number of Phases:1

Number of Poles:2

Operating Frequency:50/60 Hz

Operating Temperature:60 to 75 deg C

Suitable for:Reverse Feed

Terminal Type:Screw Clamp

Trip Type:Non-Interchangeable

Type:Thermal Magnetic

Voltage Rating:120/240 V

Wire Size:14 to 8 12 to 8 AWG
