Description

Meets all UL 498 requirements. Triple wire line contacts provide excellent long-term plug retention. Arc-resistant thermostat face. Side wire terminals accept up to #10 solid or stranded wire. Terminal screws backed out. Tamper resistant receptacles have a UL Listed shutter system. 20 amp, 125 volt.

Detailed Product Specifications

Manufacturer Part Number:TR1877V-BXSP

Unit of Measure:EA

Color:Ivory

Current Rating:20 A

Dimensions:4.19 in L x 1.3 in W x 0.87 in D

Material:PVC

Mounting Type:Flush

NEMA Configuration:NEMA 5-20

Number of Poles:2

Number Of Wires:3

Operating Temperature:-20 to 60 deg C

Voltage Rating:125 V

Wire Size:14 to 10 AWG

Wiring Type:Side
