Description

SharkBite Max reducing tees are designed to connect PEX, copper, CPVC, PE-RT or HDPE SDR-9 pipe of different sizes. Approved for underground and behind-the-wall applications with no access panels, Max reducing tees allow for fast and easy installation when joining two different size pipe.

Detailed Product Specifications

Manufacturer Part Number:UR454A

Unit of Measure:EA

Feature:Half the insertion effort, double the burst pressure

Feature:Can be installed on wet lines and pressure tested immediately

Feature:Stainless steel retainer adds strength and durability

Feature:High-performance DZR lead-free brass body

Feature:No special tools, crimping, soldering or glue required

Feature:Can be rotated after installation

Feature:No tube liner required for PEX

Feature:Can be easily removed using a disconnect clip, disconnect tongs or pro disconnect tool

Connection Type:PTC x PTC x PTC

Material:Brass

Nominal Size:3/4 x 1/2 x 1/2 in

Operating Temperature:200 deg F

Pressure Rating:250 psi

Suitable for:PEX Copper CPVC PE-RT or HDPE SDR-9 Pipe
