Description

The SDWS Framing screw is designed and load-rated for replacing 16d, 10d and 8d nails in framing applications. The SDWS Framing screw is great to nails in holding power and pull-out resistance. It is code listed in IAPMO UES ER-192 and meets 2018 and 2021 IRC® and IBC® code requirements for most common wood framing applications. The screw has a SawTooth® point that makes for fast installations with reduced torque without predrilling and its specially designed head countersinks easily to provide a clean, flush finish. The T25 bit holds the 6-lobe recess tightly for more secure drive control.

Detailed Product Specifications

Manufacturer Part Number:SDWS16312QR50

Unit of Measure:BX50

Feature:Large head with underhead box-nibs provides increased bearing in structural applications and provides clean and easy countersinking (0.44 in head Dia)

Feature:SawTooth® Type-17 tip for quick starts with no predrilling

Feature:Serrated threads reduce installation torque for easier driving

Feature:The 6-lobe drive reduces driver-bit cam-outs, resulting in easier installations and longer bit life

Feature:Driver bit included (BIT25T-2)

Feature:Quik Guard® coating provides protection in indoor and outdoor applications

Applicable Materials:Wood

Color:Tan

Drive Type:T25 6-Lobe

Finish:Quik Guardreg Coating

Head Type:Low-Profile

Includes:BIT25T-2-R2 Driver Bit

Length:3-1/2

Package Quantity:50

Point Type:SawToothreg

Suitable for:T25 Bit

Thread Length:2 in

Thread Type:Serrated
