Description

SKF SNL and SE plummer block housings are the most popular SKF bearing housings on the market, developed to be the first choice for design, quality and economy.
SE plummer block housings are a new generation with a number of new features and a stronger material grade.

SNL and SE plummer block housings enable the incorporated bearings to achieve maximum service life with less need for maintenance. Different housing variants and seal designs are available, making the use of tailored housings virtually unnecessary and enabling costeffective bearing arrangements to be made.

Shaft da: 135mm

Housing Dimensions (mm)
A: 220mm
A1: 160mm
H: 323mm
H1: 160mm
H2: 60mm
J: 450mm
L: 530mm
N: 42mm
N1: 35mm
G: 30mm

Bearing seating
Ca: 106mm
Da: 270mm

Properties
Housing type Plummer/pillow block
Housing configuration Two-piece
Mounting arrangement Through shaft/Shaft end
Number of bolt holes for fasteners 2
Material, housing Cast iron
Bearing housing seal type Without
Housing lubrication feature/possibility Grease

Mass: 49,0kg

Appropriate bearings and associated components
23230 CCK/W33 Spherical roller bearing
H2330 Adapter sleeve
FRB 5/270 Locating rings 2 per housing

23230-2CS5K/VT143 Spherical roller bearing
H2330 L Adapter sleeve
FRB 5/270 Locating rings 2 per housing

22230 CCK/W33 Spherical roller bearing
H3130 Adapter sleeve
FRB 16.5/270 Locating rings 2 per housing

22230-2CS5K/VT143 Sealed spherical roller bearing
H3130 Adapter sleeve
FRB 16.5/270 Locating rings 2 per housing

C2230 K CARB Toroidal roller bearing
H3130 L Adapter sleeve
FRB 16.5/270 Locating rings 2 per housing

Seals
TSN530 L Four-lip seals
TSN530 A V-ring seals
TSN530 C Felt ring seals
TSN530 S Labyrinth seals
TSN530 ND Taconite heavy-duty seals

End cove
ASNH530
