Description

Engineered for value, Homeline™ circuit breakers are designed for fast installation, reliability and great circuit protection. With industry leading innovations and exclusive features, Square D Homeline circuit breakers are the smart, safe, reliable choice.

Detailed Product Specifications

Manufacturer Part Number:HOMT2020CP

Unit of Measure:EA

Feature:HOM one-pole standard circuit breakers (15 – 50 A)

Feature:HOM two-pole standard circuit breakers (15 – 200 A)

Feature:HOM tandem breakers (1-pole, 15/15 A, 20/20 A, 15/20 A, 20/30 A)

Feature:HOM quad tandems circuit breakers (1- and 2-pole, 15 A to 50 A)

Feature:HOM ground-fault circuit interrupters (1 and 2-pole, 15 – 50 A)

Feature:Square D arc-fault circuit-interrupters (1-pole, 15 A and 20 A)

Feature:Square D combination arc-fault circuit interrupters (1-pole, 15 A and 20 A)

Feature:Available accessories include handle attachments, filler plates, and neutral lugs

Feature:HOM sub-feed lugs, two-pole, rated 125 A and 225 A

Color:Black

Current Rating:20 A

Dimensions:1 in W x 2.98 in D x 3.13 in H

Interrupt Rating:10 kA

Mounting Type:Plug

Number of Phases:1

Number of Poles:1

Number Of Spaces:1

Operating Frequency:50/60 Hz

Operating Temperature:104 deg F

Terminal Type:Lug

Trip Sensitivity:27 A

Trip Type:Fixed

Type:Mini Tandem

Voltage Rating:120/240 V

Wire Size:14 to 8 AWG
