Description

All QO circuit breakers are equipped with the Visi-Trip™ indicator. When a Visi-Trip circuit breaker trips, the handle snaps to a midpoint position between “OFF” and “ON” and a highly visible, red indicator easily identifies the tripped breaker. This enables you to easily distinguish which breaker has tripped in a load center that may contain up to 60 different circuit breakers. QO circuit breakers have features no other manufacturer can offer. They come in many different sizes and can meet the needs of virtually every function in your home or business. These types of quality, industry exclusive products keep the Square D brand ahead of the competition and are builders’ and electrical contractors’ first choice in electrical protection.

Detailed Product Specifications

Manufacturer Part Number:QO115GFICP

Unit of Measure:EA

Feature:Shielded copper bus bar

Feature:Available in single and three phase

Feature:Ground bar is included with all main lugs load centers with three mounting locations

Feature:Convertible mains let you meet changing job-site requirements

Feature:Tangential main service knockouts

Feature:Enclosure rotates for top or bottom feed to reduce service cable waste

Feature:Qwik-Open circuit breaker protection

Feature:Exclusive Visi-Trip red indicator

Feature:Quick make – quick break mechanism

Current Rating:15 A

Dimensions:0.75 in W x 2.91 in D x 4.12 in H

Interrupt Rating:10 kA

Mounting Type:Plug

Number of Phases:1

Number of Poles:1

Number Of Spaces:1

Operating Frequency:50/60 Hz

Operating Temperature:104 deg F

Terminal Type:Pressure Contact

Trip Type:Fixed

Type:Mini

Voltage Rating:120 V

Wire Size:12 to 8 14 to 8 AWG
