Description

Key Features

•  Immediately absorbs hydrocarbons retaining up to 3x its own weight

•  No release of hydrocarbons and extremely low-pressure drop when saturated

•  Cost-effective hydrocarbon removal at high flow rates*

•  25µm rating, used solely for oil reduction

• Specialised for Hydrocarbon Reduction  – Suitable for the polishing of trace hydrocarbons, the OilOut-99 is capable of absorbing up to three times its own weight before changeout is required. Designed to remove up to 99% of dispersed hydrocarbons, the SPECTRUM SRIF is suited to applications where the inlet contamination is below 500mg/l, such as surface runoff water, CNC machine coolant and bilge separators. The OilOut-99 achieves best results as a polishing phase after primary oil removal technologies or in a double-pass system and is effective at removing a range of contaminants, including mineral oils and BTEX hydrocarbons.

* With a complex range of oils and hydrocarbons, including emulsified and dissolved, it is always recommended that a small scale trial is conducted to validate cartridge performance.

Typical Applications

• Surface runoff water

• CNC coolant

• Bilge water treatment

• Engineering waste water

Specification

• Carbon Type – Resin Impregnated Felt

• Netting – Polyethylene

• Core: Polypropylene

• Wrap: Polypropylene

• End-Caps – Polypropylene  DOE (Double Open-Ended)

• Gasket:  Buna-N

• Max Operating Temperature – 70°C

• Max Operating Pressure Differential – 1.4 Bar

• Material: Resin Impregnated Felt

• Performance: Excellent Hydrocarbon

• Micron: 25

• Length: 50″

• Diameter: Regular (2.5″)

• End-Cap – DOE (Double Open-Ended)

• Seal: Buna-N

• Flow Rate (lpm): 90

Oilout-99 Properties

Length (“)	Average Oil Removal (G)	Pressure Drop (Bar)	Flow Rate (LPM)
9 3/4	375	0.11	20
20	750	0.11	40
30	1,125	0.11	60
40	1,500	0.11	80
9 3/4BB	1,500	0.08	20
20BB	3,000	0.08	40
