Description

Trane THT2102 Low Temperature Cutout Control

Series A11 Low Temperature Cutout Control from Johnson Controls (A11A-1C) opens low with an SPST switch.Temperature range of 35-45F with a manual differential reset.The range is adjustable via a screwdriver slot. 20-feet of 1/8″ tubing with a 4-ft capillary.

Features:

• Snap-acting switch
• External temperature scale
• Easy set point adjustment with top or bottom access
• Ambient temperature of control: 0 to 140 F
• Maximum element temperature: 250 F
• For use with:
  • Low temp cutout for coils and/or pipe liquid sensing
