Description

• Capacity 500 lbs.
• Aluminum and steel construction.
• 8″ rear wheels and 2″ front swivel casters are non-marking.

Forks can be inverted for two different lift heights. Fork size: 4″W x 22.5″L x 1.75″H.

• Winch crank handle locks to secure carriage.
• Adjustable Straddle with adjustable legs 21.5″ to 36″ inside width and 29″ to 44″ outside width.
• Top of frame rollers facilitates laying truck horizontal for transport.

---

Specifications:

Part Number: 273514

Model: HWLSD-5

Capacity: 500 lb

Overall Width: 29″

Overall Height: 68″

Overall Depth: 43″

Weight: 154 lb

Max. Lift Height: 48.5″ or 71″

Base: Adjustable Straddle

Load Center: 11.25″

Min. Lowered Height: 2″ or 25″
