Description

Guardian G1898 Wall Mounted Swing Down Eye Wash

---

Application: All-stainless steel AutoFlowâ„¢ eyewash for mounting on wall. Unit is constructed entirely in stainless steel. Ideal for use in highly corrosive environments, cleanrooms and pharmaceutical applications. Spray heads swing down from storage to operational position, activating water flow. Available in a variety of spray head configurations to minimize obstructions at a sink. Note: If unit is not installed at a sink, floor drain should be provided underneath unit to prevent accumulation of water on floor.

---

Spray Head Assembly: Two GS-Plus™ spray heads. Each head has a “flip top” dust cover, internal flow control and filter to remove impurities from the water flow.

---

Valve: 1/2″ IPS plug-type valve with Teflon® coated

O-ring seals. Swinging head assembly down from storage to operational position opens orifice and activates water flow. Unit remains in operation until spray head assembly is returned to storage position.

---

Strainer: Unit is furnished with in-line strainer to protect valve and spray heads from debris in water line.

---

Mounting: Valve is installed in Type 316 stainless steel housing. Unit mounts on countertop behind sink. Furnished with hardware for securing unit to counter.

---

Construction: Type 316 stainless steel.

---

Supply: 3/8″ NPT female inlet.

---

Sign: ANSI-compliant identification sign.

---

Quality Assurance: Unit is completely assembled and water tested prior to shipment.

---

Available Option

TMV G3600LF thermostatic mixing valve precisely blends hot and cold water to deliver warm (tepid) water as required by ANSI Z358.1-2014.
